Automann Phoenix AB1DK23P-P892 Air Spring Rolling Lobe

Bottom Part # : BS08133
Bottom Plate C to C Dia. (D) : 7.87"
Bottom Plate Dia. (C) : 10.28
Bottom Plate Hole/Stud Qty : 2
Bottom Plate Type : Plastic
Bracket : AB9471P
Bumper : No
Contitech Bellows# : 9 10-17.5
Design Height (In) : 14.00
Load (Lbs)
100 PSI : 7100
Load (Lbs)
80 PSI : 5600
Max. Dia. : 12.60
Max. Height : 22.90
Min. Height : 6.70
Natural Freq. (CPM) : 64
Top Plate C to C Dia. (B) : 5.87
Top Plate Dia. (A) : 9.00
Top Plate Hole/Stud Qty : 2
Type : Rolling Lobe

• Part number: AB1DK23P-P892
• OE MFG: Contitech
• OEM Reference: 910-17.5P892
• Cross Reference: CONTITECH : 78179, 910-17.5P892; NEWAY : 90557368 |
