Automann Phoenix AB1D28C-A855 Air Spring Rolling Lobe

Automann Bellows# : 1D28C
Bottom Part # : BS05215
Bottom Plate C to C Dia. (D) : 7.87"
Bottom Plate Dia. (C) : 10.25
Bottom Plate Hole/Stud Qty : 4
Bottom Plate Type : Aluminum
Bracket : N/A
Bumper : Yes
Contitech Bellows# : 11 10.5 -21
Design Height (In) : 16.50
Load (Lbs)
100 PSI : 8800
Load (Lbs)
80 PSI : 6900
Max. Dia. : 13.70
Max. Height : 26.50
Min. Height : 8.50
Natural Freq. (CPM) : 62
Top Plate C to C Dia. (B) : 5.50
Top Plate Dia. (A) : 11.31
Top Plate Hole/Stud Qty : 2
Type : Rolling Lobe

• Part number: AB1D28C-A855
• OE MFG: Contitech
• OEM Reference: 66084
• Cross Reference: CONTITECH : 11 10.5-21 A 855, 11105-21A855, 66084; WATSON&CHALIN : AS0220, AS-0220 |
