Automann Phoenix AB1DK23P-9966 Air Spring Rolling Lobe

Automann Bellows# : 1DK23P
Bottom Part # : BS08660
Bottom Plate C to C Dia. (D) : N/A
Bottom Plate Dia. (C) : 10.00
Bottom Plate Hole/Stud Qty : 1
Bottom Plate Type : Plastic
Bracket : AB9947P
Bumper : Yes
Contitech Bellows# : 9 10-17.5
Design Height (In) : 11.00
Firestone Bellows# : 1T15M-7.5
Load (Lbs)
100 PSI : 7500
Load (Lbs)
80 PSI : 5900
Max. Dia. : 12.60
Max. Height : 22.10
Min. Height : 7.60
Natural Freq. (CPM) : 71
Top Plate C to C Dia. (B) : 5.50
Top Plate Dia. (A) : 9.00
Top Plate Hole/Stud Qty : 2
Type : Rolling Lobe

• Part number: AB1DK23P-9966
• OE MFG: Contitech
• OEM Reference: 910-175P731
• Cross Reference: CONTITECH : 64668, 910-175P731; FIRESTONE : 9966, W013589966, W01-358-9966, W017559966, W01-755-9966; REYCO : 2012401, 20124-01, 2012401A, 20124-01A, 2012401K, 20124-01K, 2012402, 20124-02, 2012412, 20124-12 |
