Dayton Parts 346-523 Steering Drag Link

Drag Link Ds1253

• Adjustable: Yes
• Adjusting Sleeve Included: Yes
• Ball Studs: Threaded Tube
• Bends: Straight
• Boot Color: Clear
• Boot Material: Urethane
• Castle Nut Included: Yes
• Color: Black
• Cotter Pin Included: Yes
• Drag Link Type: Non-Replaceable End; Straight; Threaded Tube One End
• Dust Boot Included: Yes
• End 1 Castle Nut: 346-781475
• End 1 Gender: Male
• End 1 Large Dia: 1.250 in
• End 1 Small Dia.: 1.080 in
• End 1 Taper Length: 1.360 in
• End 1 Thread Diameter: 0.875 in
• End 1 Thread Size: 0.875-14 in
• End 1 Threads Per Inch: 14
• End 2 Gender: Female
• End 2 Thread Diameter: 1.250 in
• End 2 Thread Size: 1.250-12 in RH
• End 2 Threads Per Inch: 12
• Ends: Non-Replaceable End
• Finish: Zinc Clear
• Grade Type: Standard
• Grease Fittings Included: Yes
• Greaseable: Yes
• Length: 13.18 in
• Locking Nut Included: No
• Material: Steel
• Mounting Hardware Included: Yes
• Number of Bends: 0
• Number Of Replaceable Ends: 1
• OE Application: VOLVO/MACK
• Package Contents: 1 Drag Link, Cotter Pin, and Castle Nut
• Part Number: 346-523
• Part Type: Steering - Drag Link
• Pre-Greased: Yes
• Reference Number: DS1253
• Replaceable End: Yes
• Shaft Diameter: 1.62 in
• Stud Length: 1.360 in
• Stud Thread Diameter 1: 0.875 in
• Stud Thread Diameter 2: Lock Slot
• Weight: 8.750000

• Part number: 346-523
• Cross Reference: VMRS : 015004010; OTHER : 13QC3273P18, 13QC431, 463DS1253, 463.DS1253, DS1253, E9907, E-9907, L24TV8194B01, R250350
• Product Class: Steering - Drag Link
