Haldex EL13020X El1300 Compressor, Remanufactured

Remanufactured 4-Hole Base Mount
Rotatable Head
Belt Drive
End Cap Oil Feed
Base Oil Drain
Water Cooled
Top/Flange Discharge Type
Overall Height: 11.42 in.
Overall Width: 4.79 in.
Overall Length: 8.93 in.
External Shaft Length: 2.14 in.
Approximate Weight: 44 lbs.
Notes
Port orientation viewed from front.
Changeover/Installation Instructions: L31040.
Service Units are furnished without governors and manifolds and may require head rotation and end cap rotation before installation or changeover.
Thru-drive units must not exceed 65 ft. lbs. of transmitted torque.
Include Installation Gaskets.

• OEM Part Number: N7002A Exact Replacement
• Head Rotation: Right
• Core Group: 1301
• Notes: High Capacity Replacement EL16020X
• Overall Height: 11.42 in.
• Overall Width: 4.79 in.
• Overall Length: 8.93 in.
• External Shaft Length: 2.14 in.
• Bore Diameter: 2.75 in.
• Stroke: 1.50 in.
• Turbo-Charge Pressure: 35 Max PSI
• Rated Displacement: 13.0 CFM @ 1250 RPM
• Approximate Weight: 44 lbs.

Part number: EL13020X
